Modified Epoxy Cardanol IPN Protective System for Concrete & Steel Structures

Applications

Corrosion Protection

Salient Features

The system is based on the synthesis of epoxy cardanol under vacuum. Cardanol is a phenol obtained from fractional distillation of CNSL resin. The condensation of epoxy resin with cardanol is carried out in a reaction kettle at elevated temperature under inert atmosphere. The output is checked for alkalinity and then discharged from the vessel and collected at room temperature.

Technology Package

Technology document

Techno-Economics

Investment of Rs.70 to 80 lakh for a plant of capacity 100 liters per day

Scale of Development

Lab scale

Status of Commercialization

Licenced, Technology in production

Raw Materials

Epoxy resin and hardener, cardanol and additives

Plant, Equipment and Machinery required

Reaction kettle, Mixer, Blender and other laboratory equipment.

Environmental Aspects

No specific emission study done, Paint industry norms are to be followed.

IPR Status

Not applied for Patent

For further information please contact

The Director
CSIR - Central Building Research Institute,
Roorkee – 247 667
Phone: +91 – 1332 – 272243
